3.5mm Plastic Female Audio Jack (TS/TRS/TRRS)

These plastic chassis-mount female 3.5mm audio jacks are commonly used in audio equipment, intercoms and custom electronic projects, and are compatible with headphones, headsets and microphones.

Designed for installation in a standard 5/16-inch (8mm) chassis mounting hole.

Dimensions and Layout

3.5mm Plastic Chassis Mounting Jack Dimensions

Features

Available in TS (2-conductor), TRS (3-conductor), and TRRS (4-conductor) versions
Designed for panel and chassis mounting
Suitable for repair, replacement, and custom audio projects
Compatible with headphones, headsets, microphones, audio equipment and custom cable assemblies
Solder terminals for secure wire connections

3.5mm Audio Jack Types Explained

This diagram illustrates the different types of male audio jacks used in audio equipment, including TS, TRS, TRRS, and TRRRS configurations to aid you in selecting the correct jack for your application. It shows how each connector is wired, the number of contacts it contains, and the common applications for mono audio, stereo audio, headset microphones, and balanced audio systems.

Diagram showing TS, TRS, TRRS, and TRRRS male audio plugs with labeled tip, ring, and sleeve contacts, signal assignments, ring counts, and common audio applications. Used to assist in selecting the correct jack for your application.
